Nikon AF-S DX Zoom-Nikkor 10-24mm f/3.5~4.5G ED Lens Review


A wide zoom when you need it, where you need it.

Nikon AF-S DX Zoom-Nikkor 10-24mm f/3.5~4.5G ED. Effectively a 15-36mm zoom (with 1.5X sensor factor), this lens is relatively compact and lightweight. It offers a choice between fully manual and AF with manual override via an onboard switch. And unlike a fisheye or even the 14-24, the front element is not bulbous enough to prevent use of a filter--77mm. Copyright  ©2009 Jack Neubart. All rights reserved.

Nikon AF-S DX Zoom-Nikkor 10-24mm f/3.5~4.5G ED. Effectively a 15-36mm zoom (with 1.5X sensor factor), this lens is relatively compact and lightweight. It offers a choice between fully manual and AF with manual override via an onboard switch. And unlike a fisheye or even the 14-24, the front element is not bulbous enough to prevent use of a filter--77mm. Copyright ©2009 Jack Neubart. All rights reserved.

Over the years, I’ve become enamored of wide zooms–the wider the better. One of my faves is a Tokina fisheye zoom that I practically take everywhere. But there’s only so much barrel distortion one person can take, and only so far that distortion correction can take an image–when you want to employ it, that is. Sometimes you just want to start out with straight lines wherever you can get them. So, when I heard that Nikon had a new 10-24mm lens, I was on it like an egret on a fish (hey, it’s the first metaphor that popped into my head).

I’d worked with Canon’s EF-S 10-22 mm lens–and simply loved it. At the time, I still had an APS-C Canon, but I was fast moving toward full-frame and knew the lens would not be long for this world if I bought it. So I tested it, and sadly said goodbye. Now that I’m back in the APS-C camp with the Nikon D300–and loving it!–it was time to examine yet another zoom in the ultra-wide dimension (super-wide? potato, potato–you get what I mean).

Making Choices

Okay, I know, this looks an awful lot like another lens from Nikon. But there is a difference. Considering that only a few dollars separates them, it really is a tough call choosing between the AF-S DX Zoom-Nikkor 10-24mm f/3.5~4.5G ED and AF-S DX Zoom-Nikkor 12-24mm f/4G IF-ED.

Both lenses are designed for Nikon’s DX-format cameras. Weight and size are roughly the same. Where they obviously differ is in the maximum aperture: variable on the one we’re currently reviewing, fixed on the other. A fixed aperture does have its advantages, especially in low light photography at the longer end of the zoom range–but I’m not sure that’s enough of an argument here. The red band does denote a more professional series–if that matters (on some lenses, it means they’re weatherproof).

However, don’t forget that APS-C sensor factor of 1.5X. At the 24mm end, both lenses give us 36mm–an excellent choice for group shots. At the short end, the 12-24 comes up short–or should I say, long?–at 18mm. Wide, yes, but not quite as wide as 15mm that we effectively get on the 10-24.

Now, before you ask, no, this is not the same as a fisheye of this focal length. My fisheye zoom is a 10-17–but it’s designed to produce fisheye perspective, replete with a whole barrel of monkeys’ worth of distortion. Just the way I like it, when I want that much distortion. And the fisheye takes in a field of view equal to 180 degrees. The 10-24 only goes as wide as 109 degrees, which falls far short of fisheye. But there’s a very positive side to that, as we shall see.

Unfortunately, I haven’t worked with the 12-24, so I can’t say for certain which is the better lens. And admittedly, even if I had, different samples off the shelf may lead to completely different conclusions. Which is why I’m not too keen on bench tests. I prefer real-world testing.

But, if you really want to take your photography to the next level, then you should be considering the AF-S NIKKOR 14-24mm f/2.8G ED, which costs–and weighs–twice as much (and is designed for FX and DX cameras). That f/2.8 maximum aperture sure is sweet. All three lenses feature Nikon’s Silent Wave Motor for faster and more efficient AF operation, and mandated on certain lower-end Nikon DSLRs.

The Glass Is the Thing

Enough meandering. Let’s get back on point. As with many of the better lenses we surround ourselves with, the 10-24 is not wanting for exotic glass. The lens boasts ED (extra-low-dispersion) lens elements, aspherical elements, and Nikon’s own Super Integrated Coating. Regrettably, the lens lacks Vibration Reduction–something I could have used when shooting under low light levels.

And while the lens does physically change in length while zooming, internal focusing guarantees that you can refocus to your heart’s content and not worry about throwing a circular polarizer out of alignment With a 77mm filter size, that means a pricey polarizer, but hopefully you’ve got one sitting around. Closest focus is 0.8 ft (0.24 m) for a maximum reproduction ratio of 0.2X.

jn_02a

From ultra to moderately wide. At the 10mm focal length setting, this lens delivers sweeping vistas, albeit less dramatic when zoomed to 24mm. I added a 77mm circular polarizer to give the sky added depth. Copyright ©2009 Jack Neubart. All rights reserved.

jn_02b

But don’t let those numbers deceive you. This lens lets you get some nice close-ups–don’t you fret. The lens also features a rounded diaphragm for more pleasing out-of-focus highlights and backgrounds at or near maximum aperture.

If, like me, you were curious as to what the “G” stands for, Nikon explains: “G-type Nikkor lenses have no aperture control ring and are intended for use on Nikon DSLRs that allow the lens aperture to be adjusted via the camera’s command dial. In addition, like D-type Nikkors, G-type optics relay subject-to-camera distance information to Nikon digital SLRs. The information is used to help determine ambient and flash exposure.”

In the Field

I happened to be working with this lens when I first came upon a beautiful caterpillar, which I’d also photographed with the Nikon 60 Micro and Canon G10. Granted, none of these shots compares with what that macro lens delivered, but you take what you can get and live with some limitations.

Irises and lilies were in bloom at various times during my testing period. These were blossoms large enough to fill the frame even with a lens such as this, at 24mm, of course. With flower close-ups the trick always is deciding what to focus on: the colorful petals or the stamens and pistils (the reproductive organs). If you’re lucky, you’ll also get some pollen grains in focus. And if you’re really lucky, some bug will accommodate you and give you something else entirely to focus on.

It's all in the details. The cropped version of each image will give you an idea of the detail captured by this lens. Copyright  ©2009 Jack Neubart. All rights reserved.

It's all in the details. The cropped version of each image will give you an idea of the detail captured by this lens. Copyright ©2009 Jack Neubart. All rights reserved.

jn_05aa1

jn_05b

jn_05bb



When I’m shooting with flash, I can stop down and almost be assured of getting practically everything I want in focus–at this focal length (macro is another story). When shooting by available light, ya may has to make yer choices. Let’s just say I was bloomin’ ecstatic with the results. Better than expected, really. To me that’s a good measure of a lens, when you can bring it in to the near limits of close focusing and still get results that bring a smile to your face. By the way, depending on your shooting angle, expect some exaggerated perspective thrown in for good measure with the lens this close to the subject.

Using the built-in flash. Look carefully and you'll see where the lens, at 24mm, blocked the built-in flash on my Nikon D300 (hint: bottom middle of frame). It gets much worse at 10mm, and would have been worse still had I left the lens shade attached. Copyright  ©2009 Jack Neubart. All rights reserved.

Using the built-in flash. Look carefully and you'll see where the lens, at 24mm, blocked the built-in flash on my Nikon D300 (hint: bottom middle of frame). It gets much worse at 10mm, and would have been worse still had I left the lens shade attached. Copyright ©2009 Jack Neubart. All rights reserved.




jn_04a

In your face! Or not. Shooting angle may determine how much perspective distortion you get when shooting wide. Again, we have to keep in mind that this is effectively 36mm at the long end--so really, not that wide. Still, get close along the horizontal axis and the forward petals of this lily seem to reach out for you (let's disregard the shadow, shall we?). Shooting from what appears to be an overhead angle--or straight into the flower in the second lily, I was able to focus attention on the interplay of light and shadow for this available light shot. I normally set focusing to manual when getting this intimate with my subjects. Copyright ©2009 Jack Neubart. All rights reserved.

jn_04b




jn_08a

Playing with perspective. Shooting wide open at 10mm at the near-focus limit (vertical shot) doesn't give you much in terms of depth of field: The background is still a blur. Contrast that with the horizontal shot where I focused in to the scene--same f/3.5 exposure, except that now we bring more into focus (not crystal clarity, mind you--just a more recognizable backdrop). By the way, I intentionally tilted this shot so that it almost makes you feel as if you're on a boat rocking with the waves (liability waiver: view at own risk--not responsible for resulting seasickness). Copyright ©2009 Jack Neubart. All rights reserved.

jn_08b


Finally, we have to look at edge-to-edge sharpness, vignetting, distortion, and lateral chromatic aberration (color fringing). At first, color fringing was not apparent–until I took a closer look. Yup, it was there near the edges and at the corners–to a mild degree. But here’s the kicker: I was looking at the image in Photoshop CS3, processed by Adobe ACR. Out of the box, you get color fringing. Process that same image in Nikon’s own Capture NX2–again without invoking any corrections while processing–and color fringing goes away–as if by magic.

Color fringing. It may not be a perfect picture, but then again, it depends what you're using to process the RAW files. The image on the left was processed in Adobe ACR (Photoshop CS3), whereas the one on the right benefited from processing in Nikon Capture NX2, which removed any and all color fringing (no additional processing, aside from cropping). Copyright  ©2009 Jack Neubart. All rights reserved.

Color fringing. It may not be a perfect picture, but then again, it depends what you're using to process the RAW files. The image on the left was processed in Adobe ACR (Photoshop CS3), whereas the one on the right benefited from processing in Nikon Capture NX2, which removed any and all color fringing (no additional processing, aside from cropping). Copyright ©2009 Jack Neubart. All rights reserved.




Vignetting was very well-controlled. If you shot a blue sky, you’d see a trickle of vignetting at or near maximum aperture. But not at disturbing levels. With most subjects, I challenge you to detect it. As for barrel distortion, the lens is said to be rectilinear, which means it renders straight lines straight. Well, that it ain’t.

Barrel distortion is apparent at the 10mm setting, but again not to the point of being overly distracting. Distortion is negligible at the 24mm end. As for edge-to-edge sharpness, as expected, sharpness falls off toward the edges, notably at larger apertures. Still, since most of my shots were stopped down enough to correct the problem, it wasn’t bothersome.

Architecture. This is a good lens for architectural studies. Processing in Nikon Capture NX2 automatically corrected some barrel distortion that was evident (though barely so) at the 10mm setting. Thankfully, it had rained and the puddle and reflection, along with overhanging branches, helped fill in the foreground and give us more perspective on this scene. Copyright  ©2009 Jack Neubart. All rights reserved.

Architecture. This is a good lens for architectural studies. Processing in Nikon Capture NX2 automatically corrected some barrel distortion that was evident (though barely so) at the 10mm setting. Thankfully, it had rained and the puddle and reflection, along with overhanging branches, helped fill in the foreground and give us more perspective on this scene. Copyright ©2009 Jack Neubart. All rights reserved.


All in all, I got pictures I’m happy with. Would I buy this 10-24mm lens over a competitive design? I’m always more comfy with something I’ve tried, so the answer would be yes. Having said that, the thought of Nikon’s two other wide zooms lingers in my mind. But if I did buy this one, would I regret my choice? No, definitely not.

King and scepter. I don't see dead people, but I do see people--or more often faces in trees and plants. Who can look at a pansy and not see a face in the pattern of petals! And this budding iris reminded me of a king and his scepter. You can easily see the crown and nose, as well as scepter. If you look closely you'll see eye and mouth. If I'd had my macro lens, I might have been better able to blur out the background--but I doubt my eye would have led me toward this image as you see it. Copyright  ©2009 Jack Neubart. All rights reserved.

King and scepter. I don't see dead people, but I do see people--or more often faces in trees and plants. Who can look at a pansy and not see a face in the pattern of petals! And this budding iris reminded me of a king and his scepter. You can easily see the crown and nose, as well as scepter. If you look closely you'll see eye and mouth. If I'd had my macro lens, I might have been better able to blur out the background--but I doubt my eye would have led me toward this image as you see it. Copyright ©2009 Jack Neubart. All rights reserved.


Verdict: Buy it. This is a versatile lens that truly delivers and will not disappoint.

For more information, visit: Nikon USA
Tech specs: at Nikon USA
Get more information and user reviews for this lens from Amazon: Nikon 10-24mm f/3.5-4.5G ED AF-S DX Nikkor Lens for Nikon Digital SLR Cameras

Comments

  1. Thank you for your review, I just got the 12-24mm f4 I have tried it for 3 days only I am impressed with the quality. I got the display lens (not used) for $650 I think that was a good price, but I would like to exchange it for the 10-24mm f3.5-4.5 because it’s wider by 10 degrees
    What is your advice?

    Thank you

  2. Well, Mufid, I have personally been eyeing the 12-24, and $650 is a good price (it’s around $950 retail/online new). The fixed maximum aperture is an asset, and I believe the 12-24 is better weatherized against the elements. Plus I’ve heard good things about it. So even though I haven’t tried it yet, I’d say, stick with the 12-24. If it delivers for you, then why switch? The next lens might not fare as well, and then you’ll have lost a golden opportunity.

  3. Thank you very much for your in sight, I will keep it.
    Thanks for the advice
    Mufid

  4. Mufid, glad I could help. I’m sure you’ll enjoy the lens.

  5. Tirthankar says:

    hi jack, I cannot decide between the nikon 10-24 and the tokina 11-16 F/2.8. It costs a lot less plus most of the reviews speaks very favorably of the tokina? what do you say?

  6. Jack Neubart says:

    Hi – I’d first recommend you bring your camera to the store and try the lenses there to see which feels better in your hands. You may discover you prefer the feel of the zoom or focusing ring on one more than the other; one may exhibit more lens creep; focusing may be noticeably faster in low light with one lens; you may not like the heft or size of the lens.

    It’s been a while since I worked with the Nikon and don’t recall working with or even handling the Tokina. Also, you should check out the focus clutch feature on the Tokina to see if that’s your cup of tea. This feature replaces the AF/MF switch on the lens. Some people like it, others don’t.

    And finally see which price better fits your budget.

    Both Nikon and Tokina make fine optics, but individual samples do vary and you may find that a lens doesn’t always perform as well or as bad as some reviewers may report. Bring a laptop with you and check it out for yourself.

    One final point: I assume your camera is APS-C compatible, not full-frame, if you’re considering these lenses. So you have to multiply the lens focal length by 1.5. Also, the Nikon lens does give you a wider range. At the long end, the 36mm equivalent focal length is useful with group portraits, whereas the Tokina maxes out at 24mm equivalent – not really useful for group shots except on rare occasion. So it also depends on what you’re planning to shoot.

    Hope this helps. Have fun with whichever lens you choose.

  7. Tirthankar says:

    Hi Jack,
    thanx for your advice and I must say that it has been most helpful to me because for me the choice wasn’t easy. I finally bought the tokina for my D80 and I’m pleased with the results. Will post some pics soon. Once again thank you, :). Tc.

  8. Tirthankar says:

    and I forgot to mention one more thing, I use the 18-135, which has served me really well and its still working impeccably and I also have the nikon 50mm 1.8, so I went for the tokina 11-16, and it suited my budget too :D.

  9. D. Hale says:

    I have a D90. Last fall I went to Nova Scotia, and some other coastal cities along the way from New York. I bought this lens before the trip. When in the cities it was perfect. Street shots and building interiors are more interesting because you can get much closer. As you found out is very good for jobs my Micro 105mm or Micro 60mm would normally do. I considered the Tokina, but it’s range is too limited, and it is not a Nikkor.

  10. Hi Jack,

    I have a D7000 and am considering a wide angle lens. I eventually want to graduate to full frame cameras and this is where the dilemma sets in.
    I do like the 10-24mm but can’t get the 14-24mm out of my head. I am going on an architectural tour soon and would like to have a wide angle around me.
    What do you suggest? Should I go for the 10-24 as its considerable cheaper plus a better fir for my DX or buy the 14-24 for once and for all (with no shopping money left for my trip :) )

  11. Jack Neubart says:

    Neha – buy the 10-24 and sell it later. First off, why buy a lens that will fit a full-frame camera if you don’t already own the camera – which will be the cost of your next trip. Personally, I own a D300 and can’t complain that it’s not full-frame. I just with it had more pixels.

    Enjoy and have a great trip!
